40°C To 100°C Temperature Range DIP LED CHIPS Red 620nm Wavelength Forward Current 20mA Designed For Electronic Displays

Product Description:

The DIP LED Chips are advanced semiconductor devices designed to offer exceptional performance and reliability in various lighting and display applications. Manufactured using high-quality Gallium Arsenide (GaAs) chip material, these LEDs provide superior efficiency and brightness, making them an excellent choice for both industrial and consumer electronics. The use of GaAs ensures excellent electron mobility and high luminous efficiency, which translates into vivid, consistent light output and robust operational stability.

Encased in a Dual In-line Package (DIP), these LED chips are designed for easy integration into a wide range of circuit boards and electronic assemblies. The DIP package type is well-known for its durability and ease of handling, allowing for straightforward manual or automated insertion into printed circuit boards (PCBs). This packaging style also aids in effective heat dissipation, which helps maintain the longevity and optimal performance of the LED chips during prolonged usage.

One of the key electrical characteristics of these DIP LED Chips is their forward voltage range, which spans from 1.8V to 3.3V. This voltage range provides flexibility for various circuit designs, enabling compatibility with different power supplies and driving methods. It ensures that the LEDs can operate efficiently while maintaining low power consumption, which is crucial for energy-saving applications and reducing overall system costs.

The chip size of these DIP LED Chips is precisely 0.5mm by 0.5mm, offering a compact footprint that allows for high-density LED arrays and intricate design layouts. This miniature size does not compromise brightness or durability; instead, it enables designers to create sophisticated lighting solutions that are both space-efficient and visually striking. The small chip dimension also contributes to faster response times and enhanced color uniformity, which is critical for applications requiring precise light control.

Durability and longevity are paramount in LED technology, and these DIP LED Chips excel in this regard with an impressive lifespan of up to 50,000 hours. This extended operational life reduces maintenance needs and replacement costs, making these LEDs ideal for applications where reliability and long-term performance are essential. Whether used in commercial lighting, signage, or specialty displays, users can trust these chips to deliver consistent illumination over many years.

The product line includes specialized variants such as the UV flat top DIP LED chip and the UV square DIP LED chip, catering to niche markets requiring ultraviolet light sources with specific emission profiles. These UV LED chips are particularly useful in sterilization, counterfeit detection, and curing applications where precise UV wavelength emission is critical. Their flat top and square designs provide different beam angles and light dispersion characteristics to suit various technical requirements.

Additionally, the RGB straw hat DIP LED variant offers full-color illumination capabilities by combining red, green, and blue LEDs into a single package. This RGB configuration enables the creation of millions of color options through color mixing, making it perfect for dynamic lighting displays, mood lighting, and decorative applications. The straw hat design enhances light diffusion and aesthetic appeal, providing softer and more uniform light output.

In summary, the DIP LED Chips made from Gallium Arsenide with their compact 0.5mm x 0.5mm chip size, versatile forward voltage range of 1.8V to 3.3V, and durable DIP packaging offer a reliable and efficient lighting solution with a lifespan reaching 50,000 hours. Specialized options like the UV flat top DIP LED chip, UV square DIP LED chip, and RGB straw hat DIP LED further extend the product’s applicability across a broad spectrum of industries and lighting needs. These features collectively make the DIP LED Chips a top choice for engineers and designers seeking high-quality, long-lasting LED components.

Features:

• Product Name: DIP LED CHIPS
• 5mm Straw Hat led chip design
• Color diffused DIP LED chip for vibrant emission
• Available Emission Colors: Red, Green, Blue, Yellow, White
• Storage Temperature Range: -40°C to +100°C
• Forward Current: 20mA
• Luminous Intensity: 1000 Mcd
• Forward Voltage: 1.8V - 3.3V
• 234 LED diode type for reliable performance

Technical Parameters:

Applications:

The DIP LED CHIPS, model number GH-DIP5MMSD-5DX, are high-quality through-hole LED chips manufactured in China. These LEDs come with CE, ROHS, LM-79, and LM-80 certifications, ensuring reliable performance and safety standards. With a chip size of 0.5mm x 0.5mm, a forward current of 20mA, and a viewing angle of 60°, these LEDs provide bright and focused illumination in various colors including red, green, blue, yellow, and white. Their efficient 0.06W dip LED diode design makes them ideal for low power consumption applications.

The versatility of the DIP LED CHIPS makes them perfect for a wide range of product application occasions and scenarios. They are widely used in electronic devices that require indicator lights, backlighting, and display panels. Their compact size and through-hole mounting type make them an excellent choice for circuit boards in consumer electronics, automotive dashboards, and household appliances. The availability of multiple emission colors allows for creative designs and functional color coding in control panels and signaling devices.

In addition to standard 5MM LEDs, this product line supports various sizes such as 3MM, 5MM, 8MM, and 10MM oval DIP LEDs, catering to different design needs. The white starw hat 5MM and 3MM LED variants are particularly popular for decorative lighting, signage, and architectural illumination due to their bright output and energy efficiency. These LEDs are also suitable for use in LED displays and digital signage, where precise color representation and consistent brightness are critical.

The DIP LED CHIPS are supplied in CANTOR PACKING, ensuring secure and organized shipment. With a minimum order quantity of 6000PCS and a supply ability of 9,000,000PCS each week, these LEDs are readily available for large-scale manufacturing. The price range of 0.001 to 0.008 per piece makes them cost-effective for bulk orders. Delivery times are quick, typically within 3-7 days, with flexible payment terms including T/T, LC, and DP, supporting smooth procurement processes.

Overall, the DIP LED CHIPS are designed for applications that demand durability, efficiency, and versatility. Whether it is for industrial equipment, consumer electronics, automotive lighting, or decorative installations, these LEDs meet the requirements of modern lighting technology. Their compatibility with different sizes such as 3MM, 5MM, 8MM, and 10MM oval DIP LEDs broadens their usability across various product designs, making them a preferred choice for manufacturers worldwide.

Customization:

Our DIP LED CHIPS product, model number GH-DIP5MMSD-5DX, offers extensive product customization services to meet your specific needs. Manufactured in CHINA, these through-hole mounted LED chips come with CE, ROHS, LM-79, and LM-80 certifications, ensuring high quality and reliability.

We specialize in various types of DIP LED chips, including the popular 10mm Straw Hat dip led chip, 8mm Straw Hat led chip, and the white straw hat 5MM 3MM led, providing versatile options for different applications. With emission colors available in Red, Green, Blue, Yellow, and White, and wavelengths of 620nm (Red), 525nm (Green), and 470nm (Blue), these chips deliver a luminous intensity of 1000 Mcd, perfect for vivid and bright lighting solutions.

The chip size is a compact 0.5mm x 0.5mm, allowing for precise and efficient designs. We offer flexible pricing ranging from 0.001 to 0.008 per piece, with a minimum order quantity of 6000PCS. Our packaging is done with CANTOR PACKING to ensure safe and secure delivery.

With a robust supply ability of 9,000,000PCS each week and a fast delivery time of 3-7 days, we are equipped to handle large-scale orders promptly. Payment terms include T/T, LC, and DP to accommodate your preferred transaction method.

Choose our DIP LED CHIPS for reliable, customizable, and high-performance LED solutions tailored to your project requirements.

Support and Services:

Our DIP LED Chips are designed to provide reliable and high-performance lighting solutions for various applications. To ensure optimal operation and longevity, please follow the recommended usage guidelines and handling procedures.

If you encounter any issues with the DIP LED Chips, please verify that the product is used within the specified electrical and environmental parameters. Avoid exceeding the maximum current and voltage ratings to prevent damage.

For installation, ensure proper soldering techniques are used to avoid thermal damage. It is recommended to use a temperature-controlled soldering iron and to limit the soldering time to minimize heat exposure.

In case of product failure or performance degradation, inspect the circuit design and connection integrity. Ensure that the LED chips are not subjected to static discharge by using appropriate anti-static measures during handling and assembly.

Our technical support team is available to assist with troubleshooting, product selection, and application advice to maximize the performance of DIP LED Chips in your projects.

We offer services including product customization, reliability testing, and bulk order assistance to meet your specific requirements.

For detailed datasheets, application notes, and firmware updates related to DIP LED Chips, please refer to our official website or product documentation resources.

Packing and Shipping:

Product Packaging:

The DIP LED Chips are carefully packaged to ensure maximum protection during transit. Each chip is placed in anti-static trays or tubes to prevent any electrostatic damage. The trays are then securely sealed and placed inside sturdy cardboard boxes with adequate cushioning materials to avoid any physical impact. Packaging is labeled clearly with product specifications, quantity, and handling instructions to facilitate easy identification and safe handling.

Shipping:

We offer reliable shipping options worldwide to deliver DIP LED Chips promptly and safely. Shipping methods include standard courier services, express delivery, and freight options for bulk orders. All packages are handled with care and tracked throughout the shipping process to ensure timely arrival. Customs documentation and compliance certifications are provided as required to guarantee smooth international shipping.

FAQ:

Q1: What certifications do DIP LED CHIPS hold?

A1: DIP LED CHIPS are certified with CE, ROHS, LM-79, and LM-80, ensuring high quality and safety standards.

Q2: What is the minimum order quantity for the GH-DIP5MMSD-5DX model?

A2: The minimum order quantity for the GH-DIP5MMSD-5DX model is 6000 pieces.

Q3: How long does it take to deliver DIP LED CHIPS after placing an order?

A3: The delivery time for DIP LED CHIPS is typically between 3 to 7 days.

Q4: What are the available payment terms for purchasing DIP LED CHIPS?

A4: We accept payment via T/T (Telegraphic Transfer) and LC.DP (Letter of Credit / Documents against Payment).

Q5: What is the pricing range for DIP LED CHIPS?

A5: The price for DIP LED CHIPS ranges from $0.001 to $0.008 per piece, depending on order quantity and specifications.
