Optical Power 000mw IR LED Chips Offering Storage Temperature -40°C To 100°C Performance in Diverse Operating Conditions

Product Description:

The IR LED CHIPS product is a high-performance infrared light-emitting diode designed to meet the demanding requirements of various applications where invisible illumination is essential. Featuring a distinct infrared color, these IR LED chips operate at a wavelength of 850nm, making them ideal for use in night vision systems, security cameras, remote controls, and other devices requiring infrared illumination. The 850nm wavelength is particularly effective for producing strong, reliable infrared light that is invisible to the naked eye but easily detected by infrared sensors and cameras.

One of the standout features of these IR LED chips is their optimized viewing angle of 120 degrees. This wide viewing angle ensures that the infrared light is dispersed over a broad area, providing extensive coverage and uniform illumination. This characteristic is especially important in applications such as surveillance and monitoring, where a wide field of view is necessary to capture clear images under low-light or no-light conditions. The 120-degree viewing angle helps maximize the efficiency of the infrared light output, reducing the number of LEDs required and thus lowering overall system costs.

The chip size of these IR LEDs is precisely engineered at 1.6mm x 0.8mm, striking a perfect balance between compactness and performance. This small form factor allows for easy integration into various electronic devices without compromising on the strength or quality of the infrared output. The compact chip size also contributes to enhanced thermal management and reliability, ensuring the IR LED chips maintain optimal performance over extended periods of use.

Another key attribute of these IR LED chips is their advanced circuit configuration, labeled as 16S6P. This circuit design refers to a series-parallel combination of 16 LEDs in series and 6 parallel strings, which significantly boosts the overall power output and efficiency. The 16S6P circuit arrangement enables the IR LED chip assembly to deliver high power infrared illumination suitable for more demanding applications, such as long-range night vision and industrial sensing. This powerful configuration also makes these chips comparable to 3W IR LED modules, providing high-intensity infrared light in a compact and efficient package.

In addition to their excellent design and performance, these IR LED chips are compatible with a range of infrared LED types, including ir led 940nm smd variants. While the IR LED chips operate at 850nm, users looking for slightly different infrared wavelengths can easily find compatible products within the same category to suit their specific needs. This flexibility makes the IR LED chips a versatile choice for developers and manufacturers working on infrared illumination solutions.

Infrared IR LED technology has become indispensable in modern electronic applications, and these IR LED chips exemplify the best characteristics of this technology. Whether used in security cameras, biometric scanners, or remote sensing devices, these chips provide reliable, efficient, and powerful infrared light output. Their combination of wavelength, viewing angle, chip size, and circuit design ensures that they deliver optimal performance under a variety of working conditions.

In summary, the IR LED CHIPS product features infrared color at an 850nm wavelength, a wide 120-degree viewing angle, a compact 1.6mm x 0.8mm chip size, and a robust 16S6P circuit configuration. These attributes make it an excellent choice for applications requiring high-quality infrared illumination. Additionally, its compatibility with related products such as ir led 940nm smd and its ability to perform similarly to a 3w ir led module further highlight its versatility and power. Whether for industrial, commercial, or consumer electronics, these IR LED chips provide a reliable and efficient solution for all infrared lighting needs.

Technical Parameters:

Applications:

The IR LED Chips, model GH-IR850SD-SDF524, are high-performance infrared light-emitting diode components manufactured in China. These 3535 IR LED chips are designed for a variety of application occasions and scenarios that require reliable and efficient infrared illumination. With a compact chip size of 1.6mm x 0.8mm, these 0805 IR LED chips are ideal for integration into compact electronic devices, making them suitable for modern technological applications.

One of the primary application scenarios for these IR LED Chips is in security and surveillance systems. Their powerful optical output, ranging from 30,000 to 42,000mw, provides excellent infrared illumination for night vision cameras and motion detectors. This capability ensures clear visibility in low-light or completely dark environments, enhancing safety and security in residential, commercial, and industrial settings.

Another common use case is in remote control devices and communication systems. The infrared IR power LED datasheet indicates superior performance and reliability under various operating conditions, with a wide operating temperature range from -40°C to 85°C. This makes the GH-IR850SD-SDF524 model suitable for use in household appliances, automotive controls, and consumer electronics that require consistent infrared signaling.

Healthcare and medical equipment also benefit from the use of these IR LED Chips. Their precise wavelength emission and high optical power make them ideal for non-invasive diagnostic devices, therapeutic equipment, and biometric sensors. The SMD package type ensures easy and efficient mounting on circuit boards, facilitating rapid assembly and production.

Industrial automation and smart home systems are additional scenarios where these IR LED chips excel. The robust design, coupled with certifications such as CE, Rohs, LM-80, and LM-79, guarantees compliance with international quality and safety standards. The chips come with a warranty of 2 years or 10,000 hours, ensuring long-term reliability in demanding environments.

For mass production needs, the IR LED Chips are offered with a minimum order quantity of 1000pcs and a competitive price range of 0.003-0.008 USD per piece. With a supply ability of 8,000,000 pieces each week and a delivery time of just 3-7 days, these IR LED Chips are highly accessible for manufacturers requiring fast turnaround. Payment terms include T/T, LC, and DP, facilitating flexible transactions.

Packaging details include secure carton packing to protect the chips during transit, ensuring they arrive in perfect condition for immediate use. Overall, the GH-IR850SD-SDF524 IR LED Chips provide an optimal solution for diverse infrared lighting needs across multiple industries, combining high performance, reliability, and cost-effectiveness.

Customization:

Our IR LED Chips product, model number GH-IR850SD-SDF524, is designed and manufactured in CHINA with a strong commitment to quality and performance. Certified with CE, Rohs, LM-80, and LM-79 standards, these IR LED chips ensure reliable and safe operation for various applications.

We specialize in product customization services tailored to your specific needs. Whether you require ir led 940nm smd, 780nm ir led, or led high power ir 850nm solutions, we can customize the forward voltage range between 1.2V - 1.4V and ensure an optimal viewing angle of 120 degrees to meet your project requirements.

Our IR LED Chips operate efficiently within a temperature range of -40°C to 85°C and can be safely stored from -40°C to 100°C, making them suitable for diverse environmental conditions. The minimum order quantity is 1000pcs, with competitive pricing ranging from $0.003 to $0.008 per piece.

We provide secure carton packing for all shipments and guarantee a swift delivery time of 3-7 days. Payment terms include T/T, LC, and DP to accommodate various customer preferences. With a supply ability of 8,000,000 pieces each week, we ensure a steady and reliable supply chain for your business needs.

Contact us today to customize your IR LED Chips and benefit from high-quality, efficient, and cost-effective infrared LED solutions that fit your exact specifications.

Support and Services:

Our IR LED Chips are designed to provide high efficiency and reliability for a wide range of infrared applications. To ensure optimal performance, please follow the recommended handling and usage guidelines.

When integrating IR LED Chips into your products, avoid exposing them to static electricity and handle them with proper anti-static precautions. Use appropriate current-limiting resistors to prevent damage from excessive current.

For soldering, use a temperature-controlled soldering iron and avoid prolonged exposure to high temperatures. It is recommended to follow the reflow soldering profile specified in the datasheet to prevent thermal damage.

If you encounter any issues with the IR LED Chips, please verify the electrical connections, polarity, and operating conditions. Ensure that the operating voltage and current are within the specified limits.

We offer technical consultation and support to help you integrate our IR LED Chips effectively into your applications. Detailed datasheets, application notes, and design resources are available to assist your development process.

For optimal performance and longevity, store the IR LED Chips in a dry, static-free environment and avoid exposure to direct sunlight or extreme temperatures before use.

Our technical support team is committed to providing prompt assistance to resolve any product-related inquiries or concerns. We encourage customers to provide detailed information about their application and operating conditions for more effective support.

Packing and Shipping:

Product Packaging: The IR LED chips are carefully packaged in anti-static trays or reels to protect them from electrostatic discharge and physical damage during transportation. Each package is sealed with moisture barrier bags and includes desiccants to prevent moisture absorption. The packaging is clearly labeled with product specifications, batch numbers, and handling instructions to ensure easy identification and safe handling.

Shipping: The products are shipped using reliable courier services with options for air or sea freight depending on the order size and destination. All shipments are securely packed in sturdy cartons with adequate cushioning materials to prevent impact damage. Shipping documents, including the packing list, invoice, and certificate of conformity, are provided to ensure smooth customs clearance and delivery. Tracking information is shared with customers for real-time updates on the shipment status.

FAQ:

Q1: What is the model number of the IR LED Chips?

A1: The model number of the IR LED Chips is GH-IR850SD-SDF524.

Q2: Where are the IR LED Chips manufactured?

A2: The IR LED Chips are manufactured in China.

Q3: What certifications do the IR LED Chips have?

A3: The IR LED Chips have CE, Rohs, LM-80, and LM-79 certifications.

Q4: What is the minimum order quantity for the IR LED Chips?

A4: The minimum order quantity for the IR LED Chips is 1000 pieces.

Q5: What are the payment terms and delivery time for the IR LED Chips?

A5: Payment terms include T/T, LC, and DP. The delivery time is typically 3-7 days.

Q6: What is the price range per piece for the IR LED Chips?

A6: The price ranges from $0.003 to $0.008 per piece.

Q7: How are the IR LED Chips packaged for shipment?

A7: The IR LED Chips are packed in cartons for shipment.

Q8: What is the supply capacity of the IR LED Chips?

A8: The supply ability is 8,000,000 pieces each week.
