Various Colors 4 pin led smd 3528 Gallium Phosphide GaP Gallium Nitride GaN surface mount device led components for electronic applications

Product Description:

The 3528 LED Chips are a versatile and highly reliable lighting solution designed to meet a wide range of illumination needs. With a compact chip size of 3.5mm x 2.8mm, these surface-mount device (SMD) LEDs offer excellent performance while maintaining a small form factor. This makes them ideal for various applications where space is limited but high-quality lighting is essential.

One of the standout features of the 3528 LED Chips is their packaging type, which is Tape and Reel. This packaging method ensures the chips are protected during transportation and handling, facilitating easy automated assembly processes in manufacturing environments. This efficient packaging supports high-volume production runs, making the 3528 LED Chips a preferred choice for many industries.

In terms of application, these LED chips are particularly well-suited for backlighting, indicator lights, and decorative lighting. Their ability to produce consistent and vibrant light makes them perfect for enhancing the visibility and aesthetics of electronic devices, signage, and architectural features. Whether used in commercial displays or residential decorative setups, the 3528 LED Chips deliver outstanding illumination quality.

The operating temperature range of the 3528 LED Chips is another significant advantage. These LEDs can function reliably within a broad temperature spectrum from -40°C to +85°C. This wide range ensures stable operation in various environmental conditions, from cold outdoor installations to warmer indoor settings. The robust temperature tolerance also contributes to the longevity and durability of the LEDs, reducing maintenance and replacement costs over time.

For those seeking specific product information, the smd led 3825 white data sheet provides detailed technical specifications and performance characteristics, enabling engineers and designers to integrate these LEDs into their projects confidently. This resource is invaluable for understanding the electrical and optical properties of the chips, ensuring optimal application and performance.

The cool white led 3528 variant is particularly popular for applications requiring bright and clean white light. This color temperature is ideal for both functional and aesthetic lighting purposes, providing a crisp and modern look that enhances visibility and ambiance. The cool white LEDs are widely used in backlighting for displays, keyboards, and other electronic components where clarity and brightness are paramount.

In addition to white variants, the product range includes high quality 3528 smd led red yellow options. These colorful LEDs are perfect for indicator lights and decorative purposes, offering vivid and eye-catching illumination. The red and yellow LEDs maintain the same high standards of brightness, efficiency, and longevity as their white counterparts, making them a reliable choice for signaling and accent lighting.

Overall, the 3528 LED Chips combine compact size, robust packaging, versatile application potential, and excellent temperature tolerance, making them a top-tier choice for a variety of lighting projects. Their availability in cool white, red, and yellow colors further expands their usability across different industries and design requirements. Whether you are designing backlighting solutions, indicator lights, or decorative lighting installations, these high-quality LED chips provide dependable performance and superior light output.

Choosing the 3528 LED Chips means investing in a proven, high-performance lighting component that meets modern standards for efficiency and durability. Their trusted design and comprehensive data sheet support make them an essential component for professionals seeking reliable and effective LED lighting solutions.

Features:

• Product Name: 3528 LED CHIPS
• Luminous Flux: 6-8 Lumens Per Chip
• Lifespan: 50,000 Hours
• Power Consumption: 0.06W Per Chip
• Viewing Angle: 120 Degrees
• Chip Size: 3.5mm x 2.8mm
• Includes 3528 RGB LED options for versatile color applications
• Comes with a white LED datasheet 3528 for detailed specifications
• Features the precise 3528 SMD LED 630nm chip for optimal performance

Technical Parameters:

Applications:

The Led 3528 Chips, model number GH-SMD3528SDDF0FF, are high-quality LED chips manufactured in China, designed for versatile lighting applications. Certified with EN62754, LM-79, and LM-80 standards, these chips guarantee reliable performance and longevity. With a chip size of 3.5mm x 2.8mm and made from premium materials such as Gallium Phosphide (GaP) or Gallium Nitride (GaN), these LEDs are available in various colors including white, red, green, blue, and yellow, making them ideal for multiple lighting needs.

These LED chips are perfect for backlighting purposes in devices such as LCD screens, keyboards, and automotive dashboards, where uniform and bright illumination is essential. Their compact size and efficient forward current of 20mA allow for energy-saving, high-brightness lighting solutions that are both durable and cost-effective. The white LED datasheet 3528 highlights their excellent luminous efficiency and stable color output, which is crucial for applications requiring consistent white light.

Indicator lights also benefit greatly from the Led 3528 Chips. Whether used in household appliances, electronic devices, or industrial equipment, these LEDs provide clear and vibrant signals to users. The 4 pin led smd 3528 configuration ensures easy integration into circuit boards, offering flexibility in design and installation. Their availability in amber smd led 3528 variants adds to their versatility, catering to specific signaling and decorative lighting requirements.

Decorative lighting scenarios, such as accent lighting, signage, and holiday decorations, are enhanced by the vivid color options of these chips. Their small size and bright output make them suitable for creating eye-catching visual effects in both indoor and outdoor environments. Packed securely in carton packing, Led 3528 Chips can be supplied quickly with a delivery time of 3-7 days and a supply ability of 6,000,000 pieces each week, making them a reliable choice for large-scale projects.

With a minimum order quantity of 4000PCS and competitive pricing ranging from 0.001 to 0.003 per piece, these LEDs offer excellent value. Payment terms include T/T, DP, and LC, providing flexibility for international buyers. Overall, the Led 3528 Chips are a dependable and versatile solution for backlighting, indicator lights, and decorative lighting applications, meeting diverse industrial and commercial lighting needs.

Customization:

Our product customization services for the 3528 LED CHIPS, branded as Led 3528 Chips with model number GH-SMD3528SDDF0FF, offer tailored solutions to meet your specific needs. Manufactured in China, these 3528 smd led 630nm chip units come with certifications including EN62754, LM-79, and LM-80, ensuring high quality and reliability.

We cater to a minimum order quantity of 4000PCS, with pricing ranging from 0.001 to 0.003 per chip. Each order is carefully packed using carton packing to ensure safe delivery. Our efficient delivery time is between 3 to 7 days, supported by flexible payment terms such as T/T, DP, and LC.

With a robust supply ability of 6,000,000PCS each week, we are equipped to handle large-scale orders. The 3528 smd led chips feature a viewing angle of 120 degrees and are made from premium materials like Gallium Phosphide (GaP) or Gallium Nitride (GaN). These chips operate within a temperature range of -40°C to +85°C, guaranteeing performance under various conditions.

Each chip measures 3.5mm x 2.8mm and consumes 0.06W of power, making them efficient and compact for diverse applications. For detailed specifications, please refer to the white led datasheet 3528 provided with the product.

Support and Services:

Our 3528 LED Chips are designed to provide reliable and efficient lighting solutions for a variety of applications. We offer comprehensive technical support to ensure optimal performance and longevity of your LED products.

Technical support includes guidance on installation, heat management, electrical specifications, and troubleshooting common issues. Our team can assist with selecting the appropriate LED chips for your specific project requirements and advise on compatible drivers and accessories.

We also provide detailed datasheets and application notes to help you understand the electrical and mechanical characteristics of the 3528 LED Chips. For any performance-related inquiries or custom requirements, our experts are available to offer tailored advice.

In addition to support, we offer services such as product customization, quality assurance testing, and supply chain assistance to ensure you receive consistent and high-quality LED components.

Our commitment is to deliver exceptional service and technical expertise to help you achieve the best results with your 3528 LED Chip applications.

Packing and Shipping:

Product Packaging:

The 3528 LED chips are carefully packaged to ensure safe transportation and storage. Each batch of LED chips is sealed in anti-static bags to prevent damage from static electricity. These bags are then placed in sturdy cardboard boxes with appropriate cushioning materials to protect the chips from physical impact. The packaging is clearly labeled with product specifications, quantity, and handling instructions to ensure proper identification and care during transit.

Shipping:

We offer reliable shipping options for the 3528 LED chips, including standard and expedited delivery services. All shipments are tracked and insured to guarantee delivery safety. The products are shipped from our warehouse promptly after order confirmation, and we provide estimated delivery times based on the destination. International shipping is available with customs documentation prepared to facilitate smooth clearance. Customers are advised to check local import regulations to avoid any delays.

FAQ:

Q1: What is the model number of the Led 3528 Chips?

A1: The model number of the Led 3528 Chips is GH-SMD3528SDDF0FF.

Q2: Where are the Led 3528 Chips manufactured?

A2: The Led 3528 Chips are manufactured in China.

Q3: What certifications do the Led 3528 Chips have?

A3: The Led 3528 Chips are certified with EN62754, LM-79, and LM-80.

Q4: What is the minimum order quantity and pricing for the Led 3528 Chips?

A4: The minimum order quantity is 4000 pieces, and the price ranges from $0.001 to $0.003 per chip.

Q5: How are the Led 3528 Chips packaged and what is the delivery time?

A5: The Led 3528 Chips are packed in cartons, and the delivery time is between 3 to 7 days.

Q6: What payment terms are accepted for purchasing Led 3528 Chips?

A6: The accepted payment terms are T/T, DP, and LC.

Q7: What is the supply capacity for the Led 3528 Chips?

A7: The supply ability is 6,000,000 pieces each week.
